Introduction

Last updated 20/02/2026

Overview

DimensionIQWidgetCallbacks

defines the contract between the host application and the

DimensionIQWidget

.

The widget itself is a heavy event-driven component. It does not directly persist or own domain data. Instead, it notifies the host application when something needs to occur (create, update, delete, load, close, etc).

The host application is responsible for:

• Storing data
• Persisting chnages
• Validating operations
• Enforcing business rules
• Returning the final result back to the widget

All communication from the widget to the host happens through the

callbacks

property, which must implement the

DimensionIQWidgetCallbacks

interface.

Why This Interface Exists

The

DimensionIQWidget

is intentionally designed to:

• Be framework-agnostic
• Avoid direct data persistence
• Remain decoupled from backend APIs
• Work with any storage mechanism (REST, GraphQL, local state, IndexedDB, etc.)

This separation ensures:

• Clear ownership of data in the host application
• Full control over validation and business logic
• Predictable, testable integration patterns

Core Design Pattern

Every callback in

DimensionIQWidgetCallbacks

:

1. Receives domain data required to perform the operation
2. Receives an
   onResponse
   function
3. Must call
   onResponse(result) when the operation completes

There are no promises requires by the widget contract.

The onResponse Contract

Every callback includes:

onResponse: (result: DIQ_Result) => void

The

DIQ_Result

type communicates success or failure back to the widget.

Example structure:

interface DIQ_Result {
    ok: boolean;
    message?: string;
}

• ok: true
  - operation succeeded
• ok: false
  - operation failed
• message
  - optional context (error details, validation feedback, etc)

Interface Definition

Example

export interface DimensionIQWidgetCallbacks {

    onProjectNew: (
        project: DIQ_Project,
        onResponse: (result: DIQ_Result) => void
    ) => void;

    onProjectClose: (
        project: DIQ_Project,
        onResponse: (result: DIQ_Result) => void
    ) => void;

    onDrawingAdd: (
        drawing: DIQ_Drawing,
        onResponse: (result: DIQ_Result) => void
    ) => void;
}

note

The full interface includes many additional callbacks for the widget

Example Implementation

const callbacks: DimensionIQWidgetCallbacks = {

  onProjectNew: (project, onResponse) => {

    try {
      saveProjectToDatabase(project);

      onResponse({
        ok: true
      });

    } catch (error) {

      onResponse({
        ok: false,
        message: "Failed to create project"
      });
    }
  },

  onDrawingAdd: (drawing, onResponse) => {

    api.createDrawing(drawing)
      .then(() => {
        onResponse({ ok: true });
      })
      .catch(() => {
        onResponse({
          ok: false,
          message: "Unable to add drawing"
        });
      });
  }

};

Important Rules

1. Always Call onReponse

Failing to call

onResponse

may leave the widget in an undefined state. This can cause:

• UI lock states
• Incomplete operations
• Desynchronized state

2. The Widget is Stateless for Persistence

The widget assumes:

• The host owns the data
• The host determines success/failure
• The host enforces business rules

The widget only reacts to the result.

3. The Validation Belongs to the Host

If an operation is invalid:

onResponse({
    ok: false;
    message: "Project name already exists"
});

The widget will display the message appropriately.

Event Flow Example

User Action: Create new project

DimensionIQWidget

calls

onProjectNew(project, onResponse)

Host persists project

Host calls

onResponse({ ok: true})

Widget updates internal state

If failed:

Host calls

onResponse({ ok: false, message })

Widget cancels operation and displays feedback

Integration Guidelines

• Ensure all callbacks terminate by calling
  onResponse
• Keep persistence logic outside the widget
• Do not mutate objects unexpectedly after passing them back
• Treat callbacks as transactional boundaries

Summary

DimensionIQWidgetCallbacks

is the integration backbone of

DimensionIQWidget

.

It ensures:

• Clean separation of UI and data
• Deterministic state transitions
• Full host control over business logic
• Predictable event-driven architecture

This interface allows

DimensionIQWidget

to remain a powerful, flexible measurement engine while your application maintains complete ownership of data and rules.
